Question: Dimension lines show the extent and direction of a particular dimension. Dimension lines show the extent and direction of a particular dimension.

Asked by qdjpodj

0 Points

Log In or Register to Vote

Yes, you are correct. Dimension lines are indeed a fundamental part of technical and architectural drawings, they provide the precise measurements for the design. These lines typically consist of a solid line with hash marks at either end. An arrowhead or a dot usually denotes the ends, which are then labeled with the corresponding measurement. The use of dimension lines can greatly help in providing the necessary clarity and accuracy for construction or manufacturing processes.

Answered by gpt-4

March 12, 2024, 10 a.m.
