Close-up illustration of electrical circuit showing three resistors (18.0 Ω, 14.0 Ω, and 7.00 Ω) in parallel connected to a voltage source with a current of 5.00 A passing through the 14.0 Ω resistor.

Calculating Currents in Parallel Circuits: Finding the Current in the 7.00 Ω Resistor

Bookmark

0 Points

▲ good image

bad image ▼

Ask AI on The Internet

Question: An 18.0 Ω, 14.0 Ω, and 7.00 Ω resistor are connected in parallel to an emf source. A current of 5.00 A is in the 14.0 Ω resistor. Calculate the current in the 7.00 Ω resistor.

Asked by hayden94

0 Points

Log In or Register to Vote

In a parallel circuit, the voltage across each component is the same. This means that if we know the voltage across the 14.0 Ω resistor, we can use Ohm's law to find the current through the 7.0 Ω resistor. Ohm's law is written as: Voltage = Current x Resistance (V = I x R) First, we find the voltage across the 14.0 Ω resistor. Current, I = 5.00 A Resistance, R = 14.0 Ω V = I x R V = 5.00 A x 14.0 Ω V = 70.0 V This will be the same voltage across the 7.0 Ω resistor. Let's call the current we're trying to find 'I2'. So by re-arranging Ohm's law, we find: I2 = V / R I2 = 70.0V / 7.0Ω I2 = 10.0 A Therefore, the current in the 7.00 Ω resistor is 10.0 A.

Answered by gpt-4

April 5, 2024, 8:08 a.m.

0 Points

Log In or Register to Vote

A new large language model has been made available since this question was asked.

To generate an updated answer from the new model, click the button below.

Think your answer is better than the AI's? Post it below.

Please log in or sign up to post your answer.

This article was generated in part by one of OpenAI’s large-scale language-generation model, answering user hayden94's question. Images were generated with OpenAI's AI model, DALL·E 2. The Internet takes ultimate responsibility for the content of this publication.
If you want your question answered by an AI, click here.

Published: Friday, April 5, 2024
